Lub hauv paus ntawm kev tsim cov txheej txheem me me helical caij nplooj ntoos hlav vuam posts yog nyob rau hauv kev sib koom ua ke ntawm kev sib sau precision thiab tsis tshua muaj cua sov input vuam. Cov kauj ruam tseem ceeb suav nrog kev ua kom txias txias, sib piv cov khoom siv, microsecond- qib pulse vuam, thiab kev tswj xyuas qhov tseeb. Cov khoom siv sib xyaw ua ke yog phosphor bronze / beryllium bronze + tin -plated tooj liab hlau. Vuam tsis yuav tsum tau dynamically hloov raws li txoj kab uas hla (0.03-0.5mm), nrog tam sim no (5-50A) thiab lub sij hawm (0.1-2s) kom ntseeg tau kev twb kev txuas.
Cov Khoom Tseem Ceeb: Feem ntau siv phosphor bronze (QSn6.5-0.1) lossis beryllium bronze (QBe2), muaj cov elasticity siab, qaug zog, thiab zoo conductivity.
Hlau Bonding Khoom: Tin-plated tooj liab hlau los yog silver alloy hlau yog siv los txhim kho wettability thiab interfacial bonding zog.
Cov hlau nto yuav tsum tau degreasing, pickling, thiab passivation kev kho kom tsis muaj oxide txheej cuam tshuam thaum vuam.
Txias Coiling txheej txheem
Siv lub tshuab CNC micro-coiling tshuab, xaim raug mob rau hauv cov qauv helical ntawm chav tsev kub, tswj lub suab ntawm txoj kab uas hla mus rau ± 0.02mm thiab ua kom lub suab sib xws.
Tom qab tsim, kev ntxhov siab- nyem annealing (300-400℃, 1-2 teev) yog ua kom tshem tawm cov kev ntxhov siab uas seem thiab ua kom ruaj khov ntawm qhov ntev geometric.
